Cisco CWDM-SFP10G-1330-I Compatible LINK-PP LS-CW3310-40I SFP+ 10G CWDM Duplex LC/UPC Optical Transceiver Module for Transmission (SMF, 1330nm, 40km, Industrial, DOM)The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 20km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and

Cisco CWDM-SFP10G-1310-I Compatible LINK-PP LS-CW3110-40I SFP+ 10G CWDM Duplex LC/UPC Optical Transceiver Module for Transmission (SMF, 1310nm, 40km, Industrial, DOM)The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 20km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and

Cisco CWDM-SFP10G-1290-I Compatible LINK-PP LS-CW2910-40I SFP+ 10G CWDM Duplex LC/UPC Optical Transceiver Module for Transmission (SMF, 1290nm, 40km, Industrial, DOM)The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 20km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and

Cisco CWDM-SFP10G-1270-I Compatible LINK-PP LS-CW2710-40I SFP+ 10G CWDM Duplex LC/UPC Optical Transceiver Module for Transmission (SMF, 1270nm, 40km, Industrial, DOM)The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 20km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and

Cisco QSFP-40G-SR4 Compatible LINK-PP LQ-M8540-SR4C QSFP+ 40GBASE-SR4 MPO-12/UPC Optical Transceiver Module(MMF, 850nm, 150m, DOM)The LQ-M8540-SR4C QSFP+ module adopts 12 Fibers MTP/MPO Male connectors, reaching a link up to 150m over OM4 MMF (100m over OM3). This transceiver is compliant with QSFP+ MSA, IEEE 802.3ba 40GBASE-SR4 and breakout to 4x10GBASE-SR standard. At the same time, it is completely interoperable with all standard 40GBASE-SR4 interfaces. Digital diagnostics functions are also available via the I2C interface, as specified by the QSFP+ MSA, to allow access to real-time

Cisco SFP-10G-T-80 Compatible LINK-PP LP-RJ45TG-8YC 10GBASE-T SFP+ Transceiver Module(Copper, 80m, RJ45)LP-RJ45TG-8YC Copper Small Form Pluggable (SFP) transceivers are high performance, cost effective module compliant with the 10G Ethernet and 10GBASE-T standards as specified in IEEE 802.3az, which supporting 10Gbps data- rate up to 80 meters reach over unshielded twisted-pair category 6a/7 cables. The module provides standard serial ID information compliant with SFP+ MSA, which can be accessed with address of A0h via the 2wire serial EEPROM protocol.

Cisco SFP-10G-T-S-I Compatible LINK-PP LP-RJ45TG-3YI SFP+ 10GBASE-T Copper 30m RJ-45 Transceiver Module (Copper, Industrial, 30m, RJ-45)LP-RJ45TG-3YI Copper Small Form Pluggable (SFP) transceivers are high performance, cost effective module compliant with the 10G Ethernet and 10GBASE-T standards as specified in IEEE 802.3az, which supporting 10Gbps data- rate up to 30 meters reach over unshielded twisted-pair category 6a/7 cables. The module provides standard serial ID information compliant with SFP+ MSA, which can be accessed with address of A0h via the 2wire serial EEPROM protocol.

Cisco SFP-10G-T-X Compatible LINK-PP LP-RJ45TG-3YC 10GBase-T SFP+ Transceiver Module(Copper, 30m, RJ-45)LP-RJ45TG-3YC Copper Small Form Pluggable (SFP) transceivers are high performance, cost effective module compliant with the 10G Ethernet and 10GBASE-T standards as specified in IEEE 802.3az, which supporting 10Gbps data- rate up to 30 meters reach over unshielded twisted-pair category 6a/7 cables. The module provides standard serial ID information compliant with SFP+ MSA, which can be accessed with address of A0h via the 2wire serial EEPROM protocol.

Cisco SFP-10G-BX100U Compatible LINK-PP LS-BL495510-A0C 10GBASE-BX80-U BiDi Simplex SFP+ Optical Transceiver Module(SMF, 1490nm-TX/1550nm-RX 100km, LC, DOM)The LS-BL495510-A0C SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 100km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a APD photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi Source

Cisco QSFP-100G-DR-S Compatible LINK-PP LQ-SM31100-DR1C 100GBASE-DR QSFP28 Duplex LC/UPC SMF Optical Transceiver Module (Single Lambda, SMF, 1310nm, 500m, LC, DOM)The LQ-SM31100-DR1C 100GBASE-DR Single Lambda QSFP optical transceiver module is designed for use in 100GBASE Ethernet throughput up to 500m over single mode fiber (SMF) using a wavelength of 1310nm via duplex LC connectors. The 100 Gigabit Ethernet signal is carried over a single wavelength using onboard PAM4 modulation and FEC. The transceiver includes a Broadcom chip to convert the 4x25G NRZ electrical signals to a

Cisco QSFP-4X10G-LR-S Compatible LINK-PP LQ-M3140-LR4C QSFP+ 4 x 10GBASE-LR Optical Transceiver Module (SMF, 1310nm, 10km, MTP/MPO-12, DOM)The transceiver is designed for 10km optical communication applications,which compliant to 40GBASE-LR4 of the IEEE P802.3ba standard. The module converts 4 inputs channels (ch) of 10Gb/s electrical data to 4 optical signals, and multiplexes them into a single channel for 40Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 channels signals, and converts them to 4 channel output

Cisco QSFP-100G-4W40-I Compatible LINK-PP LQ-LW100-ER4I 100G QSFP28 ZR4 Duplex LC/UPC SMF Optical Transceiver Module (SMF, 1310nm, 40km, DOM, Industrial)LINK-PP LQ-LW100-ER4I  QSFP28 Optical Transceiver Module is designed for use in 100GBASE Ethernet throughput up to 40km over single mode fiber (SMF) using a wavelength of 1310nm via duplex LC connectors. And This transceiver is compliant with IEEE 802.3ba 100GBASE-LR4 and IEEE 802.3bm CAUI-4 standard. LINK-PP Part Number LQ-LW100-ER4I  Cisco Compatible QSFP-100G-4W4

Cisco QSFP-100G-ZR4-S Compatible LINK-PP LQ-LW100-ZR4C 100GBASE-ZR4 QSFP28 Duplex LC/UPC Optical Transceiver Module(SMF, 1310nm, 80km, DOM)It is designed for 80km optical communication applications. This module contains 4- lane optical transmitter, 4-lane optical receiver and module management block including 2 wire serial inter-face. The optical signals are multiplexed to a single-mode fiber through an industry standard LC connector. A block diagram is shown in Figure 1. LINK-PP Part Number LQ-LW100-ZR4C Cisco Compatible QSFP-100

Cisco QSFP-100G-LR4-I Compatible LINK-PP LQ-LW100-LR4I 100G QSFP28 LR4 DOM Duplex LC Optical Transceiver Module(SMF, 1310nm, 10km, DOM, Industrial)The LQ-LW100-LR4I QSFP28 module provides 100GBase-LR4 throughput up to 10km over a standard pair of single mode fiber (SMF) with duplex LC connectors. This transceiver is compliant with IEEE 802.3ba 100GBASE-LR4, IEEE 802.3bm, SFF-8665 and SFF-8636 standards.  LINK-PP Part Number LQ-LW100-LR4I Cisco Compatible QSFP-100G-LR4-I Form Factor

Cisco QSFP-40G-LR4 Compatible LINK-PP LQ-CW40-LR4C QSFP+ 40GBASE-LR4 Duplex LC/UPC Optical Transceiver Module (SMF, 1310nm, 10km, LC, DOM)The QSFP+ LR4 transceivers are high performance, cost effective modules supporting data rate of 40Gbps and 10km transmission distance with SMF.The transceiver consists of three sections: 4 inputs channels (ch) of 10Gb/s electrical data to 4 CWDM optical signals,and multiplexes them into a single channel for 40Gb/s optical transmission; on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 CWDM channels signals, and

Cisco QSFP-ELR4-40G Compatible LINK-PP LQ-CW40-L24C 40GBASE-T QSFP+ Optical Transceiver Module DOM Duplex LC(SMF, 1310nm, 20km)The LQ-CW40-L24C QSFP+ FR4 transceivers are high performance, cost effective modules supporting data rate of 40Gbps and 20km transmission distance with SMF.The transceiver consists of three sections: 4 inputs channels (ch) of 10Gb/s electrical data to 4 CWDM optical signals,and multiplexes them into a single channel for 40Gb/s optical transmission; on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 CWDM channels signals, and converts
