1/2/4G Transceiver Modules

Cisco DS-SFP-FC-2G-SW Compatible LINK-PP SFP 2.5G Optical Transceiver Module (MMF, 850nm, 300m, LC, DOM) The Cisco DS-SFP-FC-2G-SW Compatible LINK-PP SFP transceivers are high performance, cost effective modules supporting data rate of 2.5Gbps and 300m transmission distance with MMF. The transceiver consists of three sections: a VCSEL laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital

Cisco SFP-GEB-T-IL Compatible LINK-PP 10/100/1000BASE-T SFP SGMII Copper 100m RJ-45 Industrial Transceiver Module The Cisco SFP-GEB-T-IL Compatible LINK-PP module is a high-performance, industrial-grade copper SFP transceiver operating over an SGMII interface. Powered by the Realtek RTL8213B chip, it supports 10/100/1000Mbps auto-negotiation and delivers reliable full-duplex links up to 100 meters over Category 5 UTP cabling. It features integrated Tx-disable and Rx_los functions as standard. Cisco Part NumberSFP-GEB-T-ILVendor NameLINK-PP Part Status Active Form Factor

Cisco GLC-TA Compatible LINK-PP 10/100/1000BASE-T SFP SGMII Copper 100m RJ-45 Transceiver Module The Cisco GLC-TA Compatible LINK-PP SFP Copper Transceiver 10/100/1000Base-T or 1000Base-T only SFP Copper Transceiver is high performance, cost effective module, compliant with the Gigabit Ethernet and 1000BASE-T standards as specified in IEEE 802. 3-2002 and IEEE 802.3ab, which supports 1000Mb/s data-rate up to 100 meters reach over twisted-pair category 5 cable. Cisco Part NumberGLC-TAVendor NameLINK-PP Part Status Active Form Factor SFP SGMII Max. Data

Cisco GLC-FE-100BX-U Compatible LINK-PP 155M SFP Specifications GLC-FE-100BX-U is a 155M SFP BiDi single-mode optical transceiver engineered to deliver bidirectional data transmission up to 10km over a single strand of fiber by pairing a 1310nm FP laser transmitter with a 1550nm PIN photodiode receiver. Cisco Part NumberGLC-FE-100BX-UVendor NameLINK-PP Form Factor SFP Max Data Rate 155Mbps Wavelength 1310nm-TX/1550nm-RX Max Cable Distance 10km Connector Simplex LC Media SMF Transmitter Type FP Receiver Type PIN TX Power -14 to

Cisco GLC-FE-100BX-D Compatible LINK-PP 155M SFP Specifications GLC-FE-100BX-D is a commercial-grade, single-strand 155M SFP BiDi optical transceiver that utilizes a precision 1550nm FP laser combined with a sensitive PIN photodetector to drive reliable full-duplex data transmission over single-mode fiber up to a 10km reach via a 1550nm-TX/1310nm-RX wavelength split. Cisco Part NumberGLC-FE-100BX-DVendor NameLINK-PP Form Factor SFP Max Data Rate 155Mbps Wavelength 1550nm-TX/1310nm-RX Max Cable Distance 10km Connector Simplex LC Media SMF

Cisco GLC-SX-MMD Compatible LINK-PP 1G SFP Specifications The Cisco GLC-SX-MMD Compatible LINK-PP module is an industrial-grade 1G SFP transceiver engineered for reliable Gigabit Ethernet over multi-mode fiber. Operating at an 850nm wavelength, it supports transmission distances up to 550 meters via duplex LC interfaces. This hot-pluggable module features digital optical monitoring (DOM) and thrives in harsh environments from -40°C to +85°C. Cisco Part NumberGLC-SX-MMDVendor NameLINK-PP Form Factor SFP Max Data Rate 1.25Gbps Wavelength 850nm Max

Cisco ONS-SI-622-SR-MM Compatible LINK-PP 622Mbps SFP Optical Transceiver Module (MMF, 1310nm, 2km, LC, DOM) The Cisco ONS-SI-622-SR-MM Compatible LINK-PP SFP transceivers are high performance, cost effective modules supporting data rate of 622Mbps and 2km transmission distance with MMF.The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472

Cisco ONS-SI-622-L1 Compatible LINK-PP 622M SFP Transceiver Module (SMF, 1550nm, 40km, LC, DOM) The Cisco ONS-SI-622-L1 Compatible LINK-PP SFP transceivers are high performance, cost effective modules supporting data rate of 622Mbps and 40km transmission distance with SMF.The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital

Cisco 10-2626-01 Compatible LINK-PP 1G SFP Specifications The Cisco 10-2626-01 Compatible LINK-PP module is a high-performance, commercial-grade SFP transceiver delivering data rates up to 1.25 Gbps. Featuring an 850nm VCSEL transmitter and a duplex LC interface, it operates efficiently over multi-mode fiber for distances up to 550 meters. Complete with digital optical monitoring support, it ensures reliable and stable gigabit network connectivity. Cisco Part Number10-2626-01Vendor NameLINK-PP Form Factor SFP Max Data Rate 1.25Gbps Wavelength 850nm Max

Cisco SFP-GE-T Compatible LINK-PP 10/100/1000BASE-T SFP Specifications Designed as a 10/100/1000BASE-T copper SFP transceiver, the SFP-GE-T integrates a hot-pluggable footprint and a compact RJ-45 connector assembly to efficiently bridge reliable 100-meter data links over standard Cat 5 twisted-pair cabling across a 0 to 70°C operating temperature range, all while drawing an exceptionally lean typical power dissipation of just 1.05W. Cisco Part NumberSFP-GE-TVendor NameLINK-PP Part Status Active Form Factor SFP SGMII Max. Data Rate 1000Mbps Max. Cable

Cisco CWDM-SFP-1470 Compatible LINK-PP 1.25G SFP CWDM Single Mode Optical Transceiver Module(1470nm,40km,SMF,Duplex LC,DOM) The Cisco CWDM-SFP-1470 Compatible LINK-PP module is a high performance, cost-effective 1.25G SFP transceiver designed for single mode fiber networks. It supports reliable data transmission up to 40 km using a CWDM DFB laser, with built-in digital diagnostics (SFF-8472) and full compliance with SFP MSA and Class 1 laser safety standards.   Cisco Part NumberCWDM-SFP-1470Vendor NameLINK-PP Form Factor SFP Max Data Rate 1.25Gbps Wavelength 1470nm Max Cable

Cisco SFP-GEB-T-IL Compatible LINK-PP 10/100/1000BASE-T SFP Specifications SFP-GEB-T-IL is an industrial-grade 10/100/1000BASE-T SFP copper transceiver module that features low power consumption, a fully metallic enclosure to reduce EMI, and a 100-meter transmission range over Cat 5 cable in extreme temperatures from -40°C to +85°C. Cisco Part NumberSFP-GEB-T-ILVendor NameLINK-PP Part Status Active Form Factor SFP SGMII Max. Data Rate 1.25G Max. Cable Distance 100m Media Cat 5 Connector RJ-45 RX_LOS Yes DOM Support No

Cisco SFP-GEB-T-IL Compatible LINK-PP 10/100/1000BASE-T SFP Specifications SFP-GEB-T-IL acts as an industrial-grade 10/100/1000BASE-T SFP copper module engineered for extreme environments, sustaining deterministic network links up to 100m over Category 5 twisted-pair cabling while effortlessly adapting to diverse host systems via its dual-architecture support for SERDES (at native 1000BASE-T) and SGMII (at 10/100/1000Mbps multi-rate compliance) across an operating temperature spectrum of -40°C to +85°C. Cisco Part NumberSFP-GEB-T-ILVendor NameLINK-PP Part

Cisco GLC-T Compatible LINK-PP 1000BASE-T SFP Specifications GLC-T is a commercial-grade 1000BASE-T copper SFP transceiver module engineered for efficient gigabit connectivity up to 100m over Cat 5 cabling, featuring a compact RJ-45 connector and an eco-conscious design that draws a typical low power dissipation of just 1.05W while housing its circuitry in a fully metallic enclosure to guarantee low electromagnetic interference across its 0°C to 70°C operating temperature range. Cisco Part NumberGLC-TVendor NameLINK-PP Part Status Active Form Factor SFP

Cisco SFP1G-SX-31-I Compatible LINK-PP 1.25G SFP Specifications The Cisco SFP1G-SX-31-I Compatible LINK-PP module is a high-performance 1.25Gbps SFP transceiver engineered for single-mode fiber infrastructure. It features a 1310nm FP laser transmitter paired with a highly sensitive PIN photodiode receiver. Operating on a stable +3.3V power supply, this hot-pluggable module fully complies with standard SFP MSA and SFF-8472 specifications. It delivers efficient gigabit data transmission. Cisco Part NumberSFP1G-SX-31-IVendor NameLINK-PP Form Factor SFP Max Data Rate

Cisco SFP1G-SX-31 Compatible LINK-PP 1.25G SFP Specifications The Cisco SFP1G-SX-31 Compatible LINK-PP module is a high-performance Small Form-factor Pluggable (SFP) transceiver module engineered for reliable 1.25Gbps data communications over single-mode fiber. This hot-pluggable module fully complies with SFP MSA and SFF-8472 industry specifications. Operating under a single +3.3V power supply, it features a stable 1310nm FP laser transmitter and integrated digital diagnostic monitoring functions. Cisco Part NumberSFP1G-SX-31Vendor NameLINK-PP Form Factor SFP Max
